IGS-NT Combi, SW Version 3.0, ©ComAp – May 2013
IGS-NT-Combi-3.0 Reference Guide.PDF
Configurable protection outputs
1. PLC State 1
2. PLC State 2
3. PLC State 3
4. PLC State 4
5. UnivState 1
6. UnivState 2
7. UnivState 3
8. UnivState 4
9. UnivState 5
10. UnivState 6
11. UnivState 7
12. UnivState 8
13. UnivState 9
14. UnivState 10
15. UnivState 11
16. UnivState 12
17. UnivState 13
18. UnivState 14
19. UnivState 15
Table of setpoints
Group: ProcCtrlMulti
Setpoint: #SysBaseLoad
This setpoint is used to adjust the requested load for the whole gen-set group
in system baseload mode (i.e. #SysLdCtrl PtM = BASELOAD). Each gen-set
takes proprtionally equal part of this total required value. The number of running
gen-sets is resolved by the power management function according to the
requested total load, gen-sets nominal power and adjusted reserves.
Setpoint: LocalBaseload
OFF, 1 .. Nomin power [kW]
This setpoint is used to adjust local baseload level. The gen-set maintains this
load instead of performing proportional load sharing whenever the total load is
high enough. Load variations are then equalized by the gen-sets with lower
priority (higher number) or by gen-sets with local baseload switched off. If the
setpoint is adjusted to 0 (OFF) the function is off. Description of the function is
available in the chapter Local baseload.
