assembmy
ADJUSTBNG S_DE TO $_DE SQUARENESS
NOTE: When making adjustments, guide b_r iock
screw must be loosened. To check squareness it must
be tightened.
a. Loosen guide bar lock screw and lower g_Jide bar
until it rests on table. Leave lock screw loose,
b. Loosen two hex head screws on top of frame tube.
c. Grasp guide bar as illustrated and move to the side
needed to square it with table. -[his wilt slide the
guide bar bracket into position.
d. Tighten hex head screws on the top of frame tube,
e. Raise guide bar 1-3/4 inches and tighter_ _j_ide bar
lock screw.
f. Check squareness. Readjust if necessary.
tP
!/y--- HEX HEAD
_ SCREWS
_ _GUiDEBAR
i _" 8RACKET
ADJUSTING UPPER BLADE GUIDE ASSEMBLY
NOTE: The upper and lower blade guides support the
blade and keep it from twisting during operation. An ad-
justment is necessary when bRades are changed or re-
placed.
1. Loosen two hex head screws in upper blade guide
assembly and slide assembly forward in the slots
until the front edge of the blade guides are approxi-
mately 1/32"from the GULLET of the saw blade.
2. Tighten two hex head screws.
NOTE: It may be necessary to back out thrust roller ad-
justment to allow thrust roller to move back from blade
to get 1/32" clearance from the gullet to edge of blade
guide.
G ULLET--_Z
"Z
l
Z
_""-...-- B LAD E GUIDE
!l
""_ I'_'---APPROX,
1132
q
ADJUSTING UPPER BLADE GUIDES
1. Loosen the two cap screws that lock the upper
blade guides and press the two guides evenly
against thesides of the blade but do not pinch the
blade. ReJease the guides and rotate the upper
wheel slightly clockwise moving the blade down,-
ward. Make sure one guide is not further away
from the blade than the other. Tighten both cap
screws.
SAW BLADE
CAP
SCREW
BLADE
GUBDE{
CAP
SCREW
13
To Next Page
