Input Card Slots 1-8, 1-16, or 1-32 (model dependent): Each slot accepts one DMC
Series input card, sold separately (refer to “DMC Input Cards” on page 55 for
information about the cards)
CPU3 Slot: Accepts one DMC-CPU3 card, included (refer to “DMC-CPU3 Card” on
page 54 for information about the card)
DM OUTPUTS 1-8, 1-16, or 1-32 (model dependent): Each slot accepts one DMC Series
output card, sold separately (refer to “DMC Output Cards” on page 71 for
information about the cards)
100-240V~3-1.2A 50/60 Hz or 100-240V~6-2.5A 50/60 Hz or 100-240V~12.5A
50/60Hz (model dependent): IEC 60320 C14 mains power inlet;
Mates with removable power cord (included)
Ground ( ): 6-32 screw, chassis ground lug
Using the Web Interface
This section provides instructions to perform the following tasks using the web interface:
• Access the Web Interface
• Navigate the Web Interface
• View or Configure Ethernet Settings
• Route Inputs to Outputs
• Set or Edit a Password
• Edit Input and Output Names
• View or Update Firmware Versions
• Reboot the System
• Restore Factory Default Settings
• View the Error Log
NOTE: Unless otherwise indicated in this guide, the web pages of the switchers are
the same.
Access the Web Interface
To access the web interface:
1. Using the Device Discovery Tool in the Crestron Toolbox™ software, find the
IP address of the switcher.
2. Open a web browser, and then go to the IP address of the switcher.
3. Enable Adobe® Flash® Player.
NOTE: The page and related dialog box or prompt that appear vary based on the
web browser being used.
