DigitalMedia Switchers Product Manual – DOC. 8418A
DMC-DVI Input Card
The DMC-DVI is a DVI/VGA input card. An HDMI output, balanced/unbalanced analog
audio input, and USB HID port are also provided.
DMC-DVI Input Card
HDMI OUT: HDMI Type A connector, female;
HDMI digital video/audio output (DVI compatible)
DVI-I: DVI-I female (or HD15 female via included adapter);
DVI (single-link), VGA/RGB, component, S-Video, or composite video input
USB HID: USB Type B connector, female;
USB device port for connection to the USB host interface of a computer or other
USB HID compliant host
AUDIO IN L, R: 5-pin 3.5 mm detachable terminal block;
Balanced/unbalanced stereo line level audio input
For additional information, visit the DMC-DVI product page on the Crestron website.
