55
SERVICE: 8-pin RJ-45 connector, female;
100BASE-TX/1000BASE-T Ethernet port;
For factory use only
Green LED indicates 100BASE-TX link is established;
Amber LED indicates 1000BASE-T link is established;
Flashing amber LED indicates Ethernet activity
USB: USB Type A connector, female;
USB 2.0 host port for connection of a USB flash drive;
For saving/loading EDID settings and for firmware update
For additional information, visit the DMC-CPU3 product page on the Crestron website.
DMC Input Cards
DMC input cards include the following:
• DMC-4KZ-C (refer to page 56)
• DMC-4KZ-C-DSP (refer to page 57)
• DMC-4KZ-HD (refer to page 58)
• DMC-4KZ-HD-DSP (refer to page 59)
• DMC-DVI (refer to page 60)
• DMC-S (refer to page 61)
• DMC-S-DSP (refer to page 62)
• DMC-S2 (refer to page 63)
• DMC-S2-DSP (refer to page 64)
• DMC-SDI (refer to page 65)
• DMC-STR (refer to page 66)
• DMC-VGA (refer to page 67)
• DMC-VID4 (refer to page 68)
• DMC-VID-BNC (refer to page 68)
• DMC-VID-RCA-A (refer to page 69)
• DMC-VID-RCA-D (refer to page 70)
