DigitalMedia Switchers Product Manual – DOC. 8418A
DMC-S2-DSP Input Card
The DMC-S2-DSP is a DigitalMedia 8G fiber input card that transports high-definition
video, audio, Ethernet, and control signals over a single strand of single-mode fiber.
An HDMI output and unbalanced analog audio output are also provided. Built-in DSP
enables multichannel surround sound signals to be decoded and downmixed to stereo.
DMC-S2-DSP Input Card
HDMI OUT: HDMI Type A connector, female;
HDMI digital video/audio output (DVI compatible)
DM IN SMF/LC: LC female optical fiber connector;
DM 8G single-mode fiber input;
Connects to the DM 8G single-mode fiber output of a DM transmitter or other
DM device
DM IN SMF/LC LED: Green LED, indicates DM link status
AUDIO OUT L, R: RCA connectors, female;
Unbalanced stereo line level audio output
For additional information, visit the DMC-S2-DSP product page on the Crestron
website.
