4 SmartConsole Utility D-Link Web Smart Switch User Manual
Device Password Manager
Select a switch from the Device List. Click on this icon to launch the Device Password Manager window.
Here you can enter a new password and confirm it.
Figure 17 – SmartConsole Device Password Manager
Multi Firmware Upgrade
Select one or many switches of the same model name from the Device List. Click on this icon to launch the
Firmware Upgrade window. Specify the Firmware Path (or Browse for one) that you are going to use. Input
the correct password of the device, and then click Upgrade. The state will show "OK" after completion, or
“Fail” if the firmware upgrade fails or cannot be completed for any reason.
Figure 18 – Firmware Upgrade
CAUTION: Do not disconnect the PC or remove
the power cord from the device until the upgrade
completes. The software may be corrupted
because of the incomplete firmware upgrade.
DHCP Refresh:
If a DHCP-client enabled switch in the Device List shows the default IP is still used, it means the device did
not receive an IP address from the DHCP server successfully. Select that switch and click the DHCP refresh
icon. Enter the correct Device Password and then click OK. The device will renew the IP address from the
DHCP server.
14

D-Link DGS-1210-10P Specifications

General

Number of queues	4
MAC address table	8000 entries
Store-and-forward	Yes
Packet buffer memory	0.5 MB
Maximum data transfer rate	1 Gbit/s
Supported data transfer rates	10/100/1000 Mbps
10G support	No
Networking standards	IEEE 802.2, IEEE 802.3, IEEE 802.3u, IEEE 802.3x
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Networking features	Gigabit Ethernet
Packet transfer speed	14.88
Connectivity technology	Wired
Ethernet interface type	Fast Ethernet, Gigabit Ethernet
DHCP features	DHCP server, DHCP client
Security algorithms	802.1x RADIUS
Switch type	-
Switch layer	L2
Fiber optic connector	SFP
SFP/SFP+ slots quantity	2
Basic switching RJ-45 Ethernet ports quantity	10
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (typical)	109.6 W
Safety	cUL, LVD
Certification	FCC, CE, IC, VCCI, C-Tick
Product color	Black
Storage temperature (T-T)	-10 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 95 %
Operating relative humidity (H-H)	10 - 95 %

Weight and Dimensions

Depth	180 mm
Width	330 mm
Height	44 mm
Weight	1840 g
