DGS-1510 Series Gigabit Ethernet SmartPro Switch Hardware Installation Guide
24
Installing Power Cord Clip
To prevent accidental removal of the AC power cord, it is recommended to install the power cord clip
together with the power cord.
NOTE: The DGS-1510-52XMP does not support the installation of the power cord clip.
With the rough side facing down, insert the Tie Wrap into the hole below the power socket.
Figure 2-5 Insert Tie Wrap to the Switch
Plug the AC power cord into the power socket of the Switch.
Figure 2-6 Connect the power cord to the Switch
