LED Indicator Color Status Description
28XMP, and
DGS-1510-
52XMP Only)
Off
Light off No power feeding
Per SFP Port
LED Indicator Color Status Description
Link/Act Green
Solid light When there is a secure connection (or link) to
1000Mbps Ethernet device at any of the ports
Blinking When there is reception or transmission of data
occurring at 1000Mbps
Per SFP+ Port
LED Indicator Color Status Description
Link/Act Green
Solid light When there is a secure connection (or link) to 10G
bps Ethernet device at any of the ports
Blinking When there is reception or transmission (i.e.
Activity--Act) of data occurring at a 10G bps port
Orange
Solid light When there is a secure connection (or link) to
1000Mbps Ethernet device at any of the ports
Blinking When there is reception or transmission (i.e.
Activity--Act) of data occurring at a 1000Mbps port
Off
Light off Link down
Port Functions
Feature Detailed Description
Console Port
RJ-45 interface for Out-Of-Band (OOB) CLI configuration
Copper Ports
Compliant with the following standards:
• IEEE 802.3 compliance
• IEEE 802.3u compliance
• IEEE 802.3ab compliance
• IEEE 802.3az compliance (100/1000Mbps)
Supports the following full-duplex operations:
• IEEE 802.3x Flow Control support for Full-Duplex mode
• IEEE 802.3af compliance (DGS-1510-28P, DGS-1510-
28XMP, and DGS-1510-52XMP Only)
• IEEE 802.3at compliance (DGS-1510-28P, DGS-1510-
28XMP, and DGS-1510-52XMP Only)
SFP Ports
Compliant with the following standards:
• IEEE 802.3z compliance
Supports to following SFP transceivers:
• DEM-302S-LX (1000BASE-LX, Single-mode, 2 km)
To Next Page
