DGS-1510 Series Gigabit Ethernet SmartPro Switch Hardware Installation Guide
37
5. Web-based Switch Configuration
Introduction
Logging onto the Web Manager
Web-based User Interface
Introduction
Most software functions of the Switch can be managed, configured, and monitored via the embedded
Web User Interface (Web UI). Manage the Switch from remote stations anywhere on the network
through a standard browser, such as Internet Explorer (version 7 and later), Mozilla Firefox, Chrome,
or Safari. The browser acts as a universal access tool and can communicate directly with the Switch
using the HTTP protocol.
Logging onto the Web Manager
To access the Web UI, simply open a standard web browser on the management PC, enter the
Switch’s default IP address into the address bar of the browser and press the Enter key.
NOTE: The default IP address of this switch is 10.90.90.90, with a subnet mask of
255.0.0.0.
Figure 5-1 IP address in Internet Explorer
NOTE: The default username is admin and the default password is admin.
This will open the user authentication window, as seen below.
Figure 5-2 Enter Network Password Window
Enter the User Name and Password in the corresponding fields and click Login. This will open the
Web UI. Management features available in the Web UI of the Switch are explained below.
