D-Link DIR-608 User Manual

71D-Link DIR-608 User Manual
Section 3 - Conguration
Service Type
Usual Service
Name:
Select an application from the drop-down menu or type a name in
the next eld.
User-defined
Service Name:
Enter a service name.
Protocol: Select TCP or UDP from the Protocol drop-down menu.
WAN Port: Enter the WAN port number.
LAN Open Port: Enter the LAN Open port number.
LAN IP Address: Enter the IP address of the computer on your local network that you
want to allow the incoming service to.
This page allows you to congure the DIR-608’s virtual server so that remote users accessing
Web services via the public IP address can be automatically redirected to local servers on
the LAN (Local Area Network). The DIR-608 is also capable of port-redirection, meaning
that incoming trac to a particular port may be redirected to a dierent port on the server
computer.
Click the Apply Changes button to save any changes made. The virtual server will then be
added to the Current Virtual Server Forwarding Table below. To delete or disable a virtual
server, click the Delete or Disable buttons in the Action eld of the virtual server in the table.
Virtual Server
Virtual Server
Virtual Server
DIR-608
Advanced
Maintenance
Service Type
Usual Service Name
AUTH
▼
User-dened Service Name
Protocol TCP
▼
WAN Port 113 (ex.5001:5010)
LAN Open Port
113
LAN IP Address
Apply Changes
Current Virtual Server Forwarding Table
Server
Name
Protocol Local IP Address Local Port WAN Port State Action
FTP tcp 192.168.11.2 21-21 21-21 Enable
Delete Disable
