D-Link DIR-803 User Manual

8D-Link DIR-803 User Manual
Section 2 - Installation
1. Turn o and unplug your DSL or Cable modem. This is required. If you have an existing router, it is strongly
recommended that you replace it with the DIR-803, instead of using both. (Refer to “Connect to an Existing
Router” on page 11 if your modem is a combo router.)
Connect to your Network
Modem
2. Connect an Ethernet cable from the yellow port labeled INTERNET on the back of the router to the Ethernet
port on your DSL or Cable modem.
5V
RESET
1A
INTERNET12LAN34
Modem
DIR-803
Internet Port (yellow)
Ethernet Port
Ethernet Cable
