D-Link DIR-825 User Manual

DIR-825 AC1200 Wave 2 MU-MIMO Wi-Fi Gigabit Router
with 3G/LTE Support and USB Port
User Manual
Configuring via Web-based Interface
WPS
On the Wi-Fi / WPS page, you can enable the function for configuration of the WLAN and select a
method for connection to the WLAN.
The WPS function helps to configure the protected wireless network automatically. Devices
connecting to the wireless network via the WPS function must support the WPS function.
!
The WPS function allows adding devices only to the basic wireless network of the router.
!
Before using the function you need to configure one of the following authentication types:
Open with no encryption, WPA2-PSK or WPA-PSK/WPA2-PSK mixed with the AES
encryption method. When other security settings are specified, controls of the WPS page
on the tab of the relevant band are not available.
Figure 104. The page for configuring the WPS function.
You can activate the WPS function via the web-based interface or the hardware WPS button on the
cover of the device.
To activate the WPS function via the hardware button, move the Enable Wi-Fi when WPS
function is activated with hardware button switch to the right on the tabs of both bands.
Then, with the device turned on, push the button, hold it for 2 seconds, and release. The WPS LED
should start blinking. In addition, upon pressing the button, the wireless interfaces of the device are
enabled if they were disabled before.
Page 132 of 249

D-Link DIR-825 Specifications

Ports & Interfaces

gigabit LAN ports	4
gigabit WAN port	1
USB port	1

Weight and Dimensions

item dimensions	4.6” x 7.6” x 1.2”
packaging dimensions	9.6” x 11.1” x 3.1”
item weight	0.7 lbs
packaging weight	2.0 lbs
