D-Link DIR-825 User Manual

DIR-825 AC1200 Wave 2 MU-MIMO Wi-Fi Gigabit Router
with 3G/LTE Support and USB Port
User Manual
Configuring via Web-based Interface
Con+guring Wired WAN Connection
This configuration step is available for the Router and WISP Repeater modes.
!
You should configure your WAN connection in accordance with data provided by your
Internet service provider (ISP). Make sure that you have obtained all necessary information
prior to configuring your connection. Otherwise contact your ISP.
1. On the Internet connection type page, click the SCAN button (available only for the
Router mode) to automatically specify the connection type used by your ISP or manually
select the needed value from the Connection type list.
2. Specify the settings necessary for the connection of the selected type.
3. If your ISP uses MAC address binding, select the Clone MAC address of your device
checkbox.
4. If the Internet access is provided via a VLAN channel, select the Use VLAN checkbox and
fill in the VLAN ID field.
5. Click the NEXT button to continue or click the BACK button to return to the previous page.
Page 57 of 249

D-Link DIR-825 Specifications

Ports & Interfaces

gigabit LAN ports	4
gigabit WAN port	1
USB port	1

Weight and Dimensions

item dimensions	4.6” x 7.6” x 1.2”
packaging dimensions	9.6” x 11.1” x 3.1”
item weight	0.7 lbs
packaging weight	2.0 lbs
