D-Link DIR-853 User Manual

DIR-853 AC1300 MU-MIMO Wi-Fi Gigabit Router
with 3G/LTE Support and USB Port 3.0
User Manual
Configuring via Web-based Interface
,%
To configure the router's local interface, go to the Connections Setup / LAN page.
IPv4
Go to the IPv4 tab to change IPv4 address, configure the built-in DHCP server, or specify MAC
address and IP address pairs.
Figure 84. Configuring the local interface. The IPv4 tab. The Local IP Address section.
Parameter Description
Local IP Address
Mode of local IP
address assignment
For the Access point, Repeater, and Client modes only.
Select the needed value from the drop-down list.
Static: the IP address, subnet mask, and the gateway IP address are
assigned manually.
Dynamic: the router automatically obtains these parameters from
the LAN DHCP server or from the router to which it connects.
IP address
The IP address of the router in the local subnet. By default, the
following value is specified: 192.168.0.1.
Mask
The mask of the local subnet. By default, the following value is
specified: 255.255.255.0.
Gateway IP address
For the Access point, Repeater, and Client modes only.
The gateway IP address which is used by the router to connect to the
Internet (e.g., for synchronizing the system time with an NTP
server). Optional.
Hostname The name of the device assigned to its IP address in the local subnet.
Page 102 of 228

D-Link DIR-853 Specifications

General

DSL WAN	No
Ethernet WAN	Yes
Wi-Fi band	Dual-band (2.4 GHz / 5 GHz)
Wi-Fi standards	802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac)
Top Wi-Fi standard	Wi-Fi 5 (802.11ac)
WLAN data transfer rate (max)	1300 Mbit/s
WLAN data transfer rate (first band)	400 Mbit/s
WLAN data transfer rate (second band)	867 Mbit/s
Networking standards	IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11d, IEEE 802.11g, IEEE 802.11n, IEEE 802.3ab, IEEE 802.3u
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Ethernet LAN interface type	Gigabit Ethernet
Ethernet LAN (RJ-45) ports	4
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	1
Product type	Tabletop router
Product color	Black
LED indicators	LAN, Power, USB, WLAN, WPS
Output current	1.5 A
Output voltage	12 V
AC input voltage	100 - 240 V
Power source type	DC
AC input frequency	50 - 60 Hz
Storage temperature (T-T)	-20 - 65 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 95 %
Operating relative humidity (H-H)	10 - 90 %
Certification	FCC, IC, CE, RCM, IPv6
Cables included	LAN (RJ-45)
Windows operating systems supported	Windows 10, Windows 7, Windows 8, Windows 8.1, Windows Vista
Security algorithms	WPA, WPA2, WPS

Weight and Dimensions

Depth	36 mm
Width	132 mm
Height	205 mm
Weight	342 g
