D-Link DIR-853 User Manual

DIR-853 AC1300 MU-MIMO Wi-Fi Gigabit Router
with 3G/LTE Support and USB Port 3.0
User Manual
Configuring via Web-based Interface
3
On the Advanced / Redirect page, you can enable notifications on the reason of the Internet
connection failure. Notifications will be displayed in the browser window when a user is attempting
to open a web site on the Internet.
Figure 140. The Advanced / Redirect page.
To configure notifications, in the Common Settings section, move the Enable redirect switch
to the right. Then, in the Reasons for Redirect section, move the needed switches to the right.
Parameter Description
Reasons for Redirect
Physical connection
error
Notifications in case of physical connection problems (the ISP's
cable is not connected, an additional device needed to access the
Internet is not connected).
The device is not
configured
Notifications in case when the device works with default settings.
No connection
Notifications in case of problems of the default WAN connection
(authorization error, the IPS's server does not respond, etc.).
Autoconfiguration
Notifications in case when the ISP's auto configuration server is
configuring the device remotely.
When you have configured the parameters, click the APPLY button.
To disable notifications, move the Enable redirect switch to the left and click the APPLY button.
Page 170 of 228

D-Link DIR-853 Specifications

General

DSL WAN	No
Ethernet WAN	Yes
Wi-Fi band	Dual-band (2.4 GHz / 5 GHz)
Wi-Fi standards	802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac)
Top Wi-Fi standard	Wi-Fi 5 (802.11ac)
WLAN data transfer rate (max)	1300 Mbit/s
WLAN data transfer rate (first band)	400 Mbit/s
WLAN data transfer rate (second band)	867 Mbit/s
Networking standards	IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11d, IEEE 802.11g, IEEE 802.11n, IEEE 802.3ab, IEEE 802.3u
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Ethernet LAN interface type	Gigabit Ethernet
Ethernet LAN (RJ-45) ports	4
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	1
Product type	Tabletop router
Product color	Black
LED indicators	LAN, Power, USB, WLAN, WPS
Output current	1.5 A
Output voltage	12 V
AC input voltage	100 - 240 V
Power source type	DC
AC input frequency	50 - 60 Hz
Storage temperature (T-T)	-20 - 65 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 95 %
Operating relative humidity (H-H)	10 - 90 %
Certification	FCC, IC, CE, RCM, IPv6
Cables included	LAN (RJ-45)
Windows operating systems supported	Windows 10, Windows 7, Windows 8, Windows 8.1, Windows Vista
Security algorithms	WPA, WPA2, WPS

Weight and Dimensions

Depth	36 mm
Width	132 mm
Height	205 mm
Weight	342 g
