D-Link DIR-853 User Manual

DIR-853 AC1300 MU-MIMO Wi-Fi Gigabit Router
with 3G/LTE Support and USB Port 3.0
User Manual
Configuring via Web-based Interface
USB Modem
This menu is designed to operate USB modems.
If the PIN code check for the SIM card inserted into your USB modem is not disabled, the relevant
notification will be displayed in the top right corner of the page.
Figure 123. The notification on the PIN code check.
Click the ENTER button. When the USB Modem / PIN page opens, enter the PIN code in the
Authorization section
15
. Click the Show icon ( ) to display the entered code. Then click the
APPLY button.
Figure 124. Entering the PIN code.
Some USB modems in the router mode and Android smartphones in the modem mode have an IP
address from the subnet which coincides with the router's local subnet. In this case, the router's
web-based interface can be unavailable. For correct operation, disconnect the device from the USB
port and reboot the router. Then access the web-based interface, go to the Connections Setup /
LAN page, and change the value of the IP address field on the IPv4 tab (for example, specify the
value 192.168.2.1). Wait until the router is rebooted.
15 For some models of USB modems it is required to disable the PIN code check on the SIM card prior to connecting
the USB modem to the router.
Page 153 of 228

D-Link DIR-853 Specifications

General

DSL WAN	No
Ethernet WAN	Yes
Wi-Fi band	Dual-band (2.4 GHz / 5 GHz)
Wi-Fi standards	802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac)
Top Wi-Fi standard	Wi-Fi 5 (802.11ac)
WLAN data transfer rate (max)	1300 Mbit/s
WLAN data transfer rate (first band)	400 Mbit/s
WLAN data transfer rate (second band)	867 Mbit/s
Networking standards	IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11d, IEEE 802.11g, IEEE 802.11n, IEEE 802.3ab, IEEE 802.3u
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Ethernet LAN interface type	Gigabit Ethernet
Ethernet LAN (RJ-45) ports	4
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	1
Product type	Tabletop router
Product color	Black
LED indicators	LAN, Power, USB, WLAN, WPS
Output current	1.5 A
Output voltage	12 V
AC input voltage	100 - 240 V
Power source type	DC
AC input frequency	50 - 60 Hz
Storage temperature (T-T)	-20 - 65 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 95 %
Operating relative humidity (H-H)	10 - 90 %
Certification	FCC, IC, CE, RCM, IPv6
Cables included	LAN (RJ-45)
Windows operating systems supported	Windows 10, Windows 7, Windows 8, Windows 8.1, Windows Vista
Security algorithms	WPA, WPA2, WPS

Weight and Dimensions

Depth	36 mm
Width	132 mm
Height	205 mm
Weight	342 g
