D-Link DIR-853 User Manual

DIR-853 AC1300 MU-MIMO Wi-Fi Gigabit Router
with 3G/LTE Support and USB Port 3.0
User Manual
Configuring via Web-based Interface
 
On the USB Modem / Basic Settings page, you can view data on the USB modem connected to
the router and enable/disable the function for automatic creation of 3G/LTE WAN connection upon
plugging a USB modem into the router.
Figure 125. The USB Modem / Basic Settings page.
If the Automatic creation of connection switch is moved to the right and the PIN code check
for the SIM card inserted into your USB modem is disabled, then an active WAN connection with
default settings (for LTE modems) or the operator's settings (for GSM modems) will be
automatically created when plugging the USB modem into the router. The connection will be
displayed on the Connections Setup / WAN page.
If you don't want to use this function, move the Automatic creation of connection switch to
the left and click the APPLY button.
When a USB modem is connected to the router, the following data are displayed in the
Information section:
Parameter Description
Vendor
The manufacturer of your USB modem.
Model The alphanumeric code of the model of your USB modem.
Revision
The revision of the firmware of your USB modem.
IMSI The code stored in the SIM card inserted to your USB modem.
IMEI
The code stored in the memory of the USB modem.
Page 154 of 228

D-Link DIR-853 Specifications

General

DSL WAN	No
Ethernet WAN	Yes
Wi-Fi band	Dual-band (2.4 GHz / 5 GHz)
Wi-Fi standards	802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac)
Top Wi-Fi standard	Wi-Fi 5 (802.11ac)
WLAN data transfer rate (max)	1300 Mbit/s
WLAN data transfer rate (first band)	400 Mbit/s
WLAN data transfer rate (second band)	867 Mbit/s
Networking standards	IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11d, IEEE 802.11g, IEEE 802.11n, IEEE 802.3ab, IEEE 802.3u
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Ethernet LAN interface type	Gigabit Ethernet
Ethernet LAN (RJ-45) ports	4
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	1
Product type	Tabletop router
Product color	Black
LED indicators	LAN, Power, USB, WLAN, WPS
Output current	1.5 A
Output voltage	12 V
AC input voltage	100 - 240 V
Power source type	DC
AC input frequency	50 - 60 Hz
Storage temperature (T-T)	-20 - 65 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 95 %
Operating relative humidity (H-H)	10 - 90 %
Certification	FCC, IC, CE, RCM, IPv6
Cables included	LAN (RJ-45)
Windows operating systems supported	Windows 10, Windows 7, Windows 8, Windows 8.1, Windows Vista
Security algorithms	WPA, WPA2, WPS

Weight and Dimensions

Depth	36 mm
Width	132 mm
Height	205 mm
Weight	342 g
