5D-Link M15 User Manual
Section 1 - Product Overview
M15 Rear
1
2
3 4 5
1 Reset Button
Insert a paperclip in the hole and wait for the Status LED turns solid red, then release to reset the router
to default settings.
2 Power Connector Connect the included power adapter here to power on the device.
3 Gigabit WAN Port Using an Ethernet cable, connect your broadband modem to this port.
4 Gigabit LAN Port Connect Ethernet devices such as computers, switches, storage (NAS) devices, and game consoles.
5 WPS
Press this button to establish an instant connection to a wireless client using Wi-Fi Protected Setup
(WPS).
