4.8.5.2.2 Tour
From main menu->Setup->System->Display->Tour, the tour interface is shown as in Figure 4-90. Here
you can set tour interval, split mode, motion detect tour and alarm tour mode.
Figure 4-90
Please refer to the following sheet for detailed information.
Check the box here to enable tour function.
Here is for you to adjust transparency. The value ranges from 5 to
120s. The default setup is 5s.
Here you can set window mode and channel group. System can
support 1/4/8/9/16/25/36-window according to device channel
amount.
Here you can set motion detect tour/alarm tour window mode.
System supports 1/8-window now.
4.8.5.3 RS232
From main menu->Setup->System->RS232, the RS232 interface is shown as in Figure 4-91.
