Control Connection Data
Analog inputs X1A: 2 and 5 Voltage signal, unipolar
bipolar
Current signal, unipolar
bipolar
Potentiometer reference value (X1A: 4)
Resolution
Accuracy
0 (2)…10 V, Rin > 312 kohm
-10…10 V, Rin > 312 kohm
0 (4)…20 mA, Rin = 100 ohm
-20…20 mA, Rin = 100 ohm
10 V ± 1%, max. 10 mA, R < 10 kohm
0.1%
±1%
Analog output X1A: 7 0 (4)…20 mA, load < 500 ohm
Auxiliary voltage X1A: 9
24 V DC ± 10%, max. 200 mA
Digital inputs X1A: 12…16
(frequency input X1A: 16)
Voltage
Type
Frequency input
Input impedance
12…24 V DC with internal or external supply
PNP and NPN
Pulse train 0…16 kHz (X1A: 16 only)
2.4 kohm
Relay output X1B: 17…19 Type
Max. switching voltage
Max. switching current
Max. continuous current
NO + NC
250 V AC / 30 V DC
0.5 A / 30 V DC; 5 A / 230 V AC
2 A rms
Digital output X1B: 20…21 Type
Max. switching voltage
Max. switching current
Frequency
Resolution
Accuracy
Transistor output PNP
30 V DC
100 mA / 30 V DC, short-circuit protected
10Hz …16 kHz
1Hz
0.2%
RS-485 interface X1C: 23…26 Cable
Termination
Isolation
Transfer rate
Communication type
Protocol
Shielded twisted pair, impedance 100…150 ohm
Daisy chained bus without drop out lines
Bus interface isolated from the drive
1.2…76.8 kbit/s
Serial, asynchronous, half duplex
Modbus
Efciency
Approximately 95 to 98% at nominal power level, depending on the drive size and options
Degrees of Protection
IP20 (cabinet installation) / UL open: Standard enclosure. The drive must be installed in a cabinet to full the requirements for
shielding from contact.
IP20 / NEMA 1: Achieved with an option kit including a hood and a connection box.
