Printed Circuit Board Connector Wiring Diagram Si18-525B
90 Printed Circuit Board Connector Wiring Diagram
1.9 Ceiling Mounted Built-in Type
Connectors Control PCB [A1P]
Note: Other designation
Control PCB [A1P]
1) X5A Connector for terminal strip (for wired remote controller)
2) X10A, X11A Connector for transformer
3) X15A Connector for float switch
4) X17A, X18A Connector for heat exchanger thermistor
5) X19A Connector for room temperature thermistor
6) X21A Connector for fan motor
7) X25A Connector for drain pump motor
8) X27A Connector for terminal strip (for inter unit wiring)
9) X33A Optional connector for wiring adaptor PCB
10) X35A Optional connector for group control adaptor
11) X60A, X61A Optional connector for interface adaptor
1) HAP Service monitor LED
To Next Page
