Daikin D-Series User Manual

Si18-525B Field Setting for SkyAir Indoor Unit
Test Operation 183
4.2 Field Setting
4.2.1 Wired Remote Controller
Note: (Field setting must be made from the remote controller in accordance with the installation
conditions.)
 Setting can be made by changing the “Mode number”, “FIRST CODE NO.”, and “SECOND
CODE NO.”.
 Refer to the following procedures for Field setting.
Procedure

Daikin D-Series Specifications

General

HSPF Rating	Up to 10.0
Cooling Capacity	9, 000 - 36, 000 BTU/h
Heating Capacity	9, 000 - 36, 000 BTU/h
Energy Efficiency Ratio (EER)	Up to 12.5
Sound Level	19 - 50 dB (Indoor), 49 - 60 dB (Outdoor)
Noise Level	19 - 50 dB (Indoor), 49 - 60 dB (Outdoor)
Power Supply	208/230V, 1-phase, 60Hz
