Daikin D-Series User Manual

Piping Diagrams Si18-525B
434 Appendix
1.3 Indoor Units
1.3.1 Wall Mounted Type
FTKS25/35DVM, FTKS20/25/35DVMA FTXS20/25/35DVMA, FTXS20/25/35DVMT
FTKS50/60BVMB, FTK(X)S50/60BVMA8,
FTXS50/60DVMT
FTKS71BVMB, FTKS71BVMA8, FTKD60FVM
FIELD PIPING
FIELD PIPING
(9.5CuT)
(6.4CuT)
7.9CuT
MAFFLER ASSY
CROSS FLOW FAN
FAN MOTOR
THERMISTOR
ON HEAT EXCH.
INDOOR UNIT
M
6.4CuT
7.0CuT
9.5CuT
HEAT EXCHANGER
REFRIGERANT FLOW
COOLING
6.4CuT
6.4CuT
4D050757A
FIELD PIPING
FIELD PIPING
(
9.5CuT
)
(
6.4CuT
)
7.9CuT
MAFFLER ASSY
CROSS FLOW FAN
FAN MOTOR
ON HEAT EXCH.
THERMISTOR
INDOOR UNIT
M
6.4CuT
7.0CuT
9.5CuT
HEAT EXCHANGER
REFRIGERANT FLOW
HEATING
COOLING
6.4CuT
6.4CuT
4D047912F
FIELD PIPING
FIELD PIPING
(
12.7CuT
)
(
6.4CuT
)
CROSS FLOW FAN
FAN MOTOR
(
7.9CuT
)
INDOOR UNIT
(
12.7CuT
)
M
HEAT EXCHANGER
REFRIGERANT FLOW
ON HEAT EXCH.
THERMISTOR
HEATING
COOLING
4D040081Q
(
15.9CuT
)
FIELD PIPING
FIELD PIPING
(
6.4CuT
)
CROSS FLOW FAN
FAN MOTOR
(
7.9CuT
)
INDOOR UNIT
(
12.7CuT
)
M
HEAT EXCHANGER
REFRIGERANT FLOW
ON HEAT EXCH.
THERMISTOR
COOLING
4D050919E

Daikin D-Series Specifications

General

HSPF Rating	Up to 10.0
Cooling Capacity	9, 000 - 36, 000 BTU/h
Heating Capacity	9, 000 - 36, 000 BTU/h
Energy Efficiency Ratio (EER)	Up to 12.5
Sound Level	19 - 50 dB (Indoor), 49 - 60 dB (Outdoor)
Noise Level	19 - 50 dB (Indoor), 49 - 60 dB (Outdoor)
Power Supply	208/230V, 1-phase, 60Hz
