FTX-N/U, FVXS-N, FDMQ-R Series EDUS091558E
11. Electric Characteristics
Indoor Unit Outdoor Unit
Power Supply Compressor OFM IFM
Hz - Volts Voltage Range MCA MFA RLA W FLA W FLA
FTX09NMVJU RXL09QMVJU
60 Hz - 208 V
60 Hz - 230 V
Max. 60 Hz, 253 V
Min. 60 Hz, 187 V
9.5 15 8.5 18 0.15 21 0.20
FTX12NMVJU RXL12QMVJU9
60 Hz - 208 V
60 Hz - 230 V
Max. 60 Hz, 253 V
Min. 60 Hz, 187 V
13.0 15 12.0 20 0.17 28 0.23
FTX15NMVJU RXL15QMVJUA
60 Hz - 208 V
60 Hz - 230 V
Max. 60 Hz, 253 V
Min. 60 Hz, 187 V
13.0 15 11.8 71 0.47 33 0.23
FTX18UVJU RXL18UMVJUA
60 Hz - 208 V
60 Hz - 230 V
Max. 60 Hz, 253 V
Min. 60 Hz, 187 V
18.7 20 18.25 76 0.47 48 0.37
FTX24UVJU RXL24UMVJUA
60 Hz - 208 V
60 Hz - 230 V
Max. 60 Hz, 253 V
Min. 60 Hz, 187 V
18.9 20 18.25 76 0.47 48 0.57
FVXS09NVJU RXL09QMVJU
60 Hz - 208 V
60 Hz - 230 V
Max. 60 Hz, 253 V
Min. 60 Hz, 187 V
9.5 15 8.5 18 0.15 12 0.21
FVXS12NVJU RXL12QMVJU9
60 Hz - 208 V
60 Hz - 230 V
Max. 60 Hz, 253 V
Min. 60 Hz, 187 V
13.0 15 12.0 20 0.17 13 0.22
FVXS15NVJU RXL15QMVJUA
60 Hz - 208 V
60 Hz - 230 V
Max. 60 Hz, 253 V
Min. 60 Hz, 187 V
13.0 15 11.8 71 0.47 23 0.29
FDMQ12RVJU RXL12QMVJU9
60 Hz - 208 V
60 Hz - 230 V
Max. 60 Hz, 253 V
Min. 60 Hz, 187 V
13.0 15 12.0 20 0.17 130 0.73
FDMQ18RVJU RXL18UMVJUA
60 Hz - 208 V
60 Hz - 230 V
Max. 60 Hz, 253 V
Min. 60 Hz, 187 V
19.5 20 18.25 76 0.47 230 1.22
FDMQ24RVJU RXL24UMVJUA
60 Hz - 208 V
60 Hz - 230 V
Max. 60 Hz, 253 V
Min. 60 Hz, 187 V
19.8 20 18.25 76 0.47 230 1.54
Symbols:
MCA
MFA
RLA
OFM
IFM
FLA
W
: Min. circuit amps
: Max. fuse amps
: Rated load amps
: Outdoor fan motor
: Indoor fan motor
: Full load amps
: Fan motor rated output
Notes:
(A)
(A)
(A)
(A)
(W)
RLA is the max current that comes in cooling operation and heating operaton.1.
Maximum allowable voltage variation between phases is 2%.2.
Select wire size based on the larger value of MCA.3.
Instead of fuse, use circuit breaker.4.
Be sure to install an earth leak detector.
(This unit uses an inverter, which means that an earth leak detector capable of
handling high harmonics must be used in order to prevent malfunctioning of the
earth leak detector.)
5.
C: 3D101519
C: 3D123799
