FTX-N/U, FVXS-N, FDMQ-R Series EDUS091558E
95
C: 3P379970-7B
3
Accessories
A Mounting plate 1 B
Titanium apatite deodorizing
filter
2 C Drain hose 1
D Insulation tape 2 E Wireless remote controller 1 F Remote controller holder 1
G
Fixing screw for remote
controller holder 1/8” × 13/16”
(M3 × 20mm)
2 H
Indoor unit xing screw
3/16” × 1” (M4 × 25mm)
9 J
Dry battery AAA. LR03
(alkaline)
2
K Operation manual 1 L Installation manual 1 M Warranty 1
Choosing an Installation Site
• Before choosing the installation site, obtain user approval.
1. Indoor unit
The indoor unit should be positioned in a place where:
1) the restrictions on installation requirements specied in “Indoor Unit Installation Diagram” on page 4 are met,
2) both the air inlet and air outlet are unobstructed,
3) the unit is not exposed to direct sunlight,
4) the unit is away from the source of heat or steam,
5) there is no source of machine oil vapour (this may shorten the indoor unit service life),
6) cool/warm air is circulated throughout the room,
7) the unit is away from electronic ignition type uorescent lamps (inverter or rapid start type) as they may affect the remote
controller range,
8) the unit is at least 3.3ft (1m) away from any television or radio set (the unit may cause interference with the picture or
sound),
9) no laundry equipment is nearby.
2. Wireless remote controller
Turn on all the uorescent lamps in the room, if any, and nd a location where remote controller signals are properly
received by the indoor unit (within 23ft (7m)).
