FTX-N/U, FVXS-N, FDMQ-R Series EDUS091558E
7
3. Specications
Model
Indoor Unit FTX09NMVJU FTX12NMVJU
Outdoor Unit
RXL09QMVJU RXL12QMVJU9
Cooling Heating Cooling Heating
Power Supply
1 φ , 60 Hz, 208 - 230 V 1 φ , 60 Hz, 208 - 230 V
Capacity Rated (Min. ~ Max.) kW 2.64 (1.30 ~ 3.20) 3.20 (1.30 ~ 4.70) 3.11 (1.30 ~ 3.90) 3.93 (1.30 ~ 5.50)
Btu/h 9,000 (4,400 ~ 10,900) 10,900 (4,400 ~ 16,000) 10,600 (4,400 ~ 13,300) 13,400 (4,400 ~ 18,800)
kcal/h 2,270 (1,120 ~ 2,750) 2,750 (1,120 ~ 4,040) 2,670 (1,120 ~ 3,350) 3,380 (1,120 ~ 4,730)
Moisture Removal gal/h 0.32 — 0.42 —
Running Current (Rated) A 3.76 - 3.40 3.95 - 3.57 4.26 - 3.85 5.12 - 4.63
Power Consumption Rated (Min. ~ Max.) W 720 (250 ~ 1,180) 760 (230 ~ 1,440) 850 (280 ~ 1,390) 1,030 (240 ~ 1,660)
Power Factor (Rated) % 92.1 - 92.1 92.6 - 92.6 96.0 - 96.0 96.7 - 96.7
COP Rated (Min. ~ Max.) W/W 3.66 (5.20 ~ 2.70) 4.20 (5.64 ~ 3.26) 3.66 (4.64 ~ 2.80) 3.80 (5.42 ~ 3.30)
EER Rated (Min. ~ Max.) Btu/h·W 12.5 (17.6 ~ 9.2) 14.3 (19.1 ~ 11.1) 12.5 (15.7 ~ 9.6) 13.0 (18.3 ~ 11.3)
SEER / HSPF 20.0 12.5 20.0 12.0
Piping
Connections
Liquid
in. (mm)
φ 1/4 (φ 6.4) φ 1/4 (φ 6.4)
Gas
in. (mm)
φ 3/8 (φ 9.5) φ 3/8 (φ 9.5)
Drain
in. (mm)
φ 5/8 (φ 16.0) φ 5/8 (φ 16.0)
Heat Insulation Both Liquid and Gas Pipes Both Liquid and Gas Pipes
Max. Interunit Piping Length ft (m) 65-5/8 (20) 65-5/8 (20)
Max. Interunit Height Di󰀨erence ft (m) 49-1/4 (15) 49-1/4 (15)
Chargeless ft (m) 32-13/16 (10) 32-13/16 (10)
Amount of Additional Charge of
Refrigerant
oz/ft
(g/m)
0.21 (20) 0.21 (20)
Indoor Unit FTX09NMVJU FTX12NMVJU
Front Panel Color White White
Airow Rate H
cfm
(m³/min)
417 (11.8) 403 (11.4) 434 (12.3) 413 (11.7)
M 297 (8.4) 328 (9.3) 311 (8.8) 321 (9.1)
L 244 (6.9) 251 (7.1) 247 (7.0) 258 (7.3)
SL 141 (4.0) 215 (6.1) 145 (4.1) 219 (6.2)
Fan Type / Motor Output W Cross Flow Fan / 21 Cross Flow Fan / 28
Speed Steps 5 Steps, Quiet, Auto 5 Steps, Quiet, Auto
Air Direction Control Right, Left, Horizontal, Downward Right, Left, Horizontal, Downward
Air Filter Removable, Washable, Mildew Proof Removable, Washable, Mildew Proof
Running Current (Rated) A 0.25 - 0.23 0.23 - 0.21 0.28 - 0.25 0.25 - 0.23
Power Consumption (Rated) W 28 - 28 25 - 25 31 - 31 28 - 28
Power Factor (Rated) % 53.8 - 52.9 52.3 - 51.8 53.2 - 53.9 53.8 - 52.9
Temperature Control Microcomputer Control Microcomputer Control
Dimensions (H × W × D) in. (mm) 11-1/4 × 30-5/16 × 8-3/4 (285 × 770 × 223) 11-1/4 × 30-5/16 × 8-3/4 (285 × 770 × 223)
Packaged Dimensions (H × W × D) in. (mm) 14-3/16 × 32-11/16 × 12 (360 × 831 × 305) 14-3/16 × 32-11/16 × 12 (360 × 831 × 305)
Weight (Mass) Lbs (kg) 18 (8) 18 (8)
Gross Weight (Gross Mass) Lbs (kg) 24 (11) 25 (12)
Sound Pressure
Level
H / M / L / SL
dB(A) 43 / 36 / 30 / 19 43 / 36 / 29 / 25 45 / 37 / 30 / 19 45 / 37 / 30 / 26
Outdoor Unit RXL09QMVJU RXL12QMVJU9
Casing Color Ivory White Ivory White
Heat Exchanger Fin / Spec. Tube
Wa󰀪e Fin (PE) / φ 7 mm Hi-XD Tube Wa󰀪e Fin (PE) / φ 7 mm Hi-XD Tube
Compressor Type Hermetically Sealed Swing Type Hermetically Sealed Swing Type
Model 1YC23AUXD 2YC36PXD
Motor Output W 790 1,100
Refrigerant Oil Type FVC50K FVC50K
Charge oz (L) 12.4 (0.375) 21.5 (0.650)
Refrigerant Type R-410A R-410A
Charge Lbs (kg) 2.09 (0.95) 2.09 (0.95)
Airow Rate H
cfm
(m³/min)
1,105 (31.3) 922 (26.1) 1,144 (32.4) 1,006 (28.5)
SL 865 (24.5) 777 (22.0) 865 (24.5) 777 (22.0)
Fan Type / Motor Output W Propeller / 18 Propeller / 20
Running Current (Rated) A 3.51 - 3.17 3.72 - 3.36 3.98 - 3.60 4.87 - 4.40
Power Consumption (Rated) W 692 - 692 735 - 735 819 - 819 1002 - 1002
Power Factor (Rated) % 94.8 - 94.9 95.1 - 95.1 98.9 - 98.9 98.9 - 99.0
Starting Current A 3.95 4.94
Dimensions (H × W × D) in. (mm) 21-5/8 × 26-9/16 × 11-3/16 (550 × 675 × 284) 21-5/8 × 26-9/16 × 11-3/16 (550 × 675 × 284)
Packaged Dimensions (H × W × D) in. (mm) 24-3/4 × 32-11/16 × 16 (629 × 830 × 407) 24-3/4 × 32-11/16 × 16 (629 × 830 × 407)
Weight (Mass) Lbs (kg) 60 (27) 70 (32)
Gross Weight (Gross Mass) Lbs (kg) 71 (32) 80 (36)
Sound Pressure Level H dB(A) 49 49 50 50
Conditions Based on Indoor ; 80°FDB (26.7°CDB) /
67°FWB (19.4°CWB)
Outdoor ; 95°FDB (35°CDB) /
75°FWB (24°CWB)
Piping Length: 25 ft (7.5 m)
Indoor ; 70°FDB (21°CDB) /
60°FWB (15.6°CWB)
Outdoor ; 47°FDB (8.3°CDB) /
43°FWB (6°CWB)
Piping Length: 25 ft (7.5 m)
Indoor ; 80°FDB (26.7°CDB) /
67°FWB (19.4°CWB)
Outdoor ; 95°FDB (35°CDB) /
75°FWB (24°CWB)
Piping Length: 25 ft (7.5 m)
Indoor ; 70°FDB (21°CDB) /
60°FWB (15.6°CWB)
Outdoor ; 47°FDB (8.3°CDB) /
43°FWB (6°CWB)
Piping Length: 25 ft (7.5 m)
Drawing No. C: 3D101720 C: 3D123801A
Notes SL: The quiet fan level of the airow rate setting. SL: The quiet fan level of the airow rate setting.
Conversion Formulae
kcal/h = kW × 860
Btu/h = kW × 3412
cfm = m3/min × 35.3
