Heating Set-Up
The Heating menu provides a summary of the control
parameters for units with heating. The unit’s heating mode
of operation is controlled by the control temperature and the
heating setpoint temperature. The unit goes into the heating
mode of operation by analyzing the control temperature.
The control temperature can be return temperature, space
temperature or outside air temperature. The unit goes into the
heating mode of operation when the control temperature is
below the heating setpoint by more than ½ the deadband.
Table 28: Heating Set-Up Menu
Item Display Name Default Setting Range Password Level
Htg Stage Time 5min 2–60min 4
Htg DB 2.0°F 1.0–10.0°F 4
Htg Period= 60s 0–999s 4
Htg Gain= 0.1 0.0–100.0 4
Htg PAT= 600s 0–999s 4
Htg Max Chg 10% 0–100% 4
Htg Hi OAT Lock 55°F 0–100°F 4
OAT Diff 2°F 0–10°F 4
Htg Reset= None
None
Ntwrk
Space
Return
OAT
ExtmA
ExtV
6
Min Htg Spt= 55.0°F 40.0–140.0°F 6
Min Htg Spt @ 0/NA
0–100/
NA
°F
°C
mA
6
Max Htg Spt= 55.0°F 40.0–140.0°F 6
Max Htg Spt @ 100.0°F
0–100/
NA
°F
°C
mA
6
Min DAT Ctrl= Ye s Yes, No 6
Min Dat Limit 55.0°F 0.0–70.0°F 4
F&BP Method= OpenVlv
OpenVlv
ModVlv
4
F&BP ChgOvrT= 37°F 0–60°F 4
Occ Heating= Yes Yes, No 6
Unocc Diff= 3°F 0–10°F 2
Htg Warmup Tm= 240s 0–999s 2
Htg Hld Period= 240s 0–999s 2
Max Purge Hld= 20s 10–180s 2
Gas Derate V= 10.0V 0–10.0V 2
MWU Sensor RAT
RAT
Space
None
2
