Daikin RXS50BVMA User Manual

Si04-306 Specifications
Specifications 17
1.3 Heat Pump - R410A Series
240V, 50Hz
Notes:

MAX. interunit piping length: 30m

MIN. interunit piping length: 1.5m

MAX. interunit height difference: 20m

Amount of additional charge of refrigerant 20g/m for piping length exceeding 10m

The data are based on the conditions shown in the table below.
Model
Indoor Units FTXS50BVMA FTXS60BVMA
Outdoor Units
RXS50BVMA RXS60BVMA
Cooling Heating Cooling Heating
Capacity
Rated (Min.~Max.)
kW 5.0 (0.9~5.8) 5.8 (0.9~7.5) 6.0 (0.9~6.7) 7.0 (0.9~8.0)
Btu/h 17,070 (3,070~19,800) 19,800 (3,070~25,610) 20,480 (3,070~22,870) 23,900 (3,070~27,310)
kcal/h 4,300 (770~4,990) 4,990 (770~6,450) 5,160 (770~5,760) 6,020 (770~6,880)
Moisture Removal L/h 2.9 — 3.9 —
Running Current (Rated) A 7.0 7.2 8.9 8.8
Power Consumption
Rated (Min.~Max.)
W 1,660 (450~2,300) 1,700 (450~2,580) 2,120 (450~2,450) 2,090 (450~3,100)
Power Factor % 98.8 98.4 99.3 99.0
COP W/W 3.01 3.41 2.83 3.35
Piping
Connections
Liquid mm
φ
6.4
φ
6.4
Gas mm
φ
12.7
φ
12.7
Drain mm
φ
18.0
φ
18.0
Heat Insulation Both Liquid and Gas Pipes Both Liquid and Gas Pipes
Indoor Unit FTXS50BVMA FTXS60BVMA
Front Panel Color White White
Air Flow Rate
m³/min
(cfm)
H 11.4 (402) 12.6 (445) 16.2 (572) 17.4 (614)
M 9.8 (346) 10.9 (385) 13.9 (491) 15.3 (540)
L 8.7 (307) 9.3 (328) 11.9 (420) 13.1 (462)
SL 7.7 (272) 8.2 (289) 10.7 (378) 11.7 (413)
Fan
Type Cross Flow Fan Cross Flow Fan
Motor Output W 40 43
Speed Steps 5 Steps, Silent and Auto 5 Steps, Silent and Auto
Air Direction Control Right, Left, Horizontal and Downward Right, Left, Horizontal and Downward
Air Filter Removable / Washable / Mildew Proof Removable / Washable / Mildew Proof
Running Current (Rated) A 0.17 0.17 0.19 0.19
Power Consumption (Rated) W 40 40 45 45
Power Factor % 98.0 98.0 98.7 98.7
Temperature Control Microcomputer Control Microcomputer Control
Dimensions (H×W×D) mm 290×795×238 290×1,050×238
Packaged Dimensions (H×W×D) mm 280×840×338 337×1,147×366
Weight kg 9 12
Gross Weight kg 13 17
Operation
Sound
H/M/L/SL dBA 44/40/35/32 42/38/33/30 45/41/36/33 44/40/35/32
Sound Power H dBA 63 60 63 62
Outdoor Unit RXS50BVMA RXS60BVMA
Casing Color Ivory White Ivory White
Compressor
Type Hermetically Sealed Swing Type Hermetically Sealed Swing Type
Model 2YC32HXD 2YC32HXD
Motor Output W 1,500 1,500
Refrigerant
Oil
Model FVC50K FVC50K
Charge L 0.65 0.65
Refrigerant
Model R410A R410A
Charge kg 1.20 1.70
Air Flow Rate
(H/L)
m³/min 47.7/44.1 44.1/44.1 47.6/44.1 45.5/45.5
cfm 1,684/1,557 1,557/1,557 1,680/1,557 1,606/1,606
Fan
Type Propeller Propeller
Motor Output W 53 53
Running Current (Rated) A 6.83 7.03 8.71 8.61
Power Consumption (Rated) W 1,620 1,660 2,075 2,045
Power Factor % 98.8 98.4 99.3 99.0
Starting Current A 7.2 8.9
Dimensions (H×W×D) mm 735×825×300 735×825×300
Packaged Dimensions (H×W×D) mm 784×960×390 784×960×390
Weight kg 49 53
Gross Weight kg 53 57
Operation
Sound
H/L dBA 47/44 48/45 49/46 49/46
Sound Power H dBA 63 64 64 64
Drawing No. 3D040798 3D040799
Conversion Formulae
kcal/h=kW×860
Btu/h=kW×3414
cfm=m³/min×35.3
Cooling Heating Piping Length
Indoor ; 27°CDB/19°CWB
Outdoor ; 35°CDB/24°CWB
Indoor ; 20°CDB
Outdoor ; 7°CDB/6°CWB
7.5m
