Specifications Si04-306
22 Specifications
1.4 Heat Pump - R22 Series
220-230-240V, 50Hz / 220-230V, 60Hz
Notes:

MAX. interunit piping length: 30m

MAX. interunit height difference: 20m

Amount of additional charge for piping length exceeding 10m : 20g/m(50/60class), 50g/m(71class)

The data are based on the conditions shown in the table below.
Model
Indoor Units FTXD50BVMA FTXD60BVMA
Outdoor Units
RXD50BVMA RXD60BVMA
Cooling Heating Cooling Heating
Capacity
Rated (Min.~Max.)
kW 5.2 (0.9~5.9) 6.5 (0.9~8.0) 6.2 (0.9~7.6) 7.2 (0.9~9.0)
Btu/h 17,750 (3,070~20,140) 22,190 (3,070~27,310) 21,170 (3,070~25,950) 24,580 (3,070~30,730)
kcal/h 4,470 (770~5,070) 5,590 (770~6,880) 5,330 (770~6,540) 6,190 (770~7,740)
Moisture Removal L/h 2.9 — 3.9 —
Running Current (Rated) A 7.4-7.0-6.7/7.4-7.0 8.5-8.1-7.7/8.5-8.1 9.6-9.2-8.8/9.6-9.2 9.7-9.3-8.9/9.7-9.3
Power Consumption
Rated (Min.~Max.)
W 1,600 (450~2,300) 1,840 (450~2,800) 2,100 (450~3,210) 2,120 (450~3,230)
Power Factor % 98.3-99.4-99.5/98.3-99.4 98.4-98.8-99.6/98.4-98.8 99.4-99.2-99.4/99.4-99.2 99.3-99.1-99.3/99.3-99.1
COP W/W 3.25 3.53 2.95 3.40
Piping
Connections
Liquid mm
φ
6.4
φ
6.4
Gas mm
φ
12.7
φ
15.9
Drain mm
φ
18.0
φ
18.0
Heat Insulation Both Liquid and Gas Pipes Both Liquid and Gas Pipes
Indoor Unit FTXD50BVMA FTXD60BVMA
Front Panel Color White White
Air Flow Rate
m³/min
(cfm)
H 16.8 (593) 17.5 (618) 17.5 (618) 18.7 (660)
M 14.0 (494) 14.9 (526) 14.6 (515) 16.1 (568)
L 11.8 (417) 12.5 (441) 12.2 (431) 13.6 (480)
SL 10.4 (367) 11.0 (388) 10.8 (381) 11.8 (417)
Fan
Type Cross Flow Fan Cross Flow Fan
Motor Output W 43 43
Speed Steps 5 Steps, Silent and Auto 5 Steps, Silent and Auto
Air Direction Control Right, Left, Horizontal and Downward Right, Left, Horizontal and Downward
Air Filter Removable / Washable / Mildew Proof Removable / Washable / Mildew Proof
Running Current (Rated) A 0.19-0.18-0.17/0.19-0.18 0.19-0.18-0.17/0.19-0.18 0.21-0.20-0.19/0.21-0.20 0.21-0.20-0.19/0.21-0.20
Power Consumption (Rated) W 40 40 45 45
Power Factor % 95.7-96.6-98.0/95.7-96.6 95.7-96.6-98.0/95.7-96.6 97.4-97.8-98.7/97.4-97.8 97.4-97.8-98.7/97.4-97.8
Temperature Control Microcomputer Control Microcomputer Control
Dimensions (H×W×D) mm 290×1,050×238 290×1,050×238
Packaged Dimensions (H×W×D) mm 337×1,147×366 337×1,147×366
Weight kg 12 12
Gross Weight kg 17 17
Operation
Sound
H/M/L/SL dBA 44/40/35/32 42/38/33/30 45/41/36/33 44/40/35/32
Sound Power H dBA 63 60 63 62
Outdoor Unit RXD50BVMA RXD60BVMA
Casing Color Ivory White Ivory White
Compressor
Type Hermetically Sealed Swing Type Hermetically Sealed Swing Type
Model 2YC32UXD 2YC45ZXD
Motor Output W 1,500 1,500
Refrigerant
Oil
Model SE50P SUNISO 4GSD.I.
Charge L 0.65 0.65
Refrigerant
Model R22 R22
Charge kg 1.25 1.80
Air Flow Rate
(H/L)
m³/min 42.8/40.7 40.7/40.7 46.3/42.9 44.2/44.2
cfm 1,511/1,437 1,437/1,437 1,634/1,514 1,560/1,560
Fan
Type Propeller Propeller
Motor Output W 53 53
Running Current (Rated) A 7.21-6.82-6.53/7.21-6.82 8.31-7.92-7.53/8.31-7.92 9.39-9.00-8.61/9.39-9.00 9.49-9.10-8.71/9.49-9.10
Power Consumption (Rated) W 1,560 1,800 2,055 2,075
Power Factor % 98.3-99.5-99.5/98.3-99.5 98.5-98.8-99.6/98.5-98.8 99.5-99.3-99.4/99.5-99.3 99.4-99.1-99.3/99.4-99.1
Starting Current A 7.7 9.0
Dimensions (H×W×D) mm 735×825×300 735×825×300
Packaged Dimensions (H×W×D) mm 784×960×390 784×960×390
Weight kg 49 55
Gross Weight kg 54 59
Operation
Sound
H/L dBA 47/44 48/45 49/46 49/46
Sound Power H dBA 63 64 64 64
Drawing No. 3D040790 3D040791
Conversion Formulae
kcal/h=kW×860
Btu/h=kW×3414
cfm=m³/min×35.3
Cooling Heating Piping Length
Indoor ; 27°CDB/19°CWB
Outdoor ; 35°CDB/24°CWB
Indoor ; 20°CDB
Outdoor ; 7°CDB/6°CWB
7.5m
