SiBE121021_C Troubleshooting for Outdoor Unit
Service Diagnosis 349
7.12 Thermistor or Related Abnormality (Outdoor Unit)
Remote
Controller
Display
H9
,
J3
,
J6
,
J8
,
J9
,
P4
Outdoor Unit LED
Display
A
j
1
i
2
i
3
h
4
h
5
h
Method of
Malfunction
Detection
This type of error is detected by checking the thermistor input voltage to the microcomputer.
A thermistor error is detected by checking the temperature sensed by each thermistor.
Malfunction
Decision
Conditions

The thermistor input is above 4.96 V or below 0.04 V with the power on.

J3
error is judged if the discharge pipe temperature is lower than the heat exchanger
temperature.

The system is shut down if all the units are judged as the
J8
error.
Supposed
Causes

Disconnection of the connector for the thermistor

Defective thermistor

Defective outdoor unit PCB

Defective indoor unit PCB

Defective heat exchanger thermistor in the case of
J3
error (outdoor heat exchanger
thermistor in cooling mode, or indoor heat exchanger thermistor in heating mode)
Troubleshooting In case of “
P4
”
Replace the outdoor unit PCB.
P4
: Radiation fin thermistor
Caution
Be sure to turn off the power switch before connecting or disconnecting
connectors, or parts may be damaged.
