SiBE121021_C Specifications
Specifications 45
1.4 Heat Pump - Outdoor Unit
50 Hz, 230 V
Note:
The data are based on the conditions shown in the table below.
Model
3MXS52E3V1B
Cooling Heating
Casing Color Ivory White
Compressor
Type Hermetically Sealed Swing Type
Model 2YC36BXD
Motor Output W 1,100
Refrigerant Oil
Model FVC50K
Charge L 0.65
Refrigerant
Type R-410A
Charge kg 2.0
Airflow Rates
H
m³/min
45 45
L4541
H
cfm
1,589 1,589
L 1,589 1,448
Fan
Type Propeller
Motor Output W 53
Running Current A H: 0.33 / L: 0.29
Power Consumption W H: 43 / L: 34
Starting Current A 6.2
Dimensions (H × W × D) mm 735 × 936 × 300
Packaged Dimensions (H × W × D) mm 797 × 992 × 390
Weight (Mass) kg 49
Gross Weight (Gross Mass) kg 56
Operation Sound dB(A) 46 47
Sound Power dB(A) 59 60
Piping
Connection
Liquid mm
φ
6.4
×
3
Gas mm
φ
9.5
×
2
, φ
12.7
×
1
Drain mm
φ
18.0
Heat Insulation Both Liquid and Gas Pipes
No. of Wiring Connection 3 for Power Supply, 4 for Interunit Wiring
Max. Interunit Piping Length
m 50 (for Total of Each Room)
m 25 (for One Room)
Amount of Additional Charge g/m 20 (30m or more)
Max. Installation Height Difference
m 15 (between Indoor Unit and Outdoor Unit)
m 7.5 (between Indoor Units)
Drawing No. 3D054327#1
Conversion Formulae
kcal/h = kW × 860
Btu/h = kW × 3412
cfm = m³/min × 35.3
Cooling Heating Piping Length
Indoor ; 27°CDB / 19°CWB
Outdoor ; 35°CDB
Indoor ; 20°CDB
Outdoor ; 7°CDB / 6°CWB
7.5 m
To Next Page
