Danfoss VLT AutomationDrive FC 300 Design Guide

5.2.4 Sine-Wave Filter Modules, 380–690 V AC
400 V, 50 Hz 460 V, 60 Hz 500 V, 50 Hz Frame size Filter ordering number
[kW] [A] [HP] [A] [kW] [A] IP00 IP23
90 177 125 160 110 160 D1h/D3h/D5h/D6h 130B3182 130B3183
110 212 150 190 132 190 D1h/D3h/D5h/D6h
130B3184 130B3185
132 260 200 240 160 240 D1h/D3h/D5h/D6h, D13
160 315 250 302 200 302 D2h/D4h, D7h/D8h, D13
130B3186 130B3187
200 395 300 361 250 361 D2h/D4h,D7h/D8h, D13
250 480 350 443 315 443
D2h/D4h, D7h, D8h, D13, E9,
F8/F9
130B3188 130B3189
315 600 450 540 355 540 E1/E2, E9, F8/F9
130B3191 130B3192
355 658 500 590 400 590 E1/E2, E9, F8/F9
400 745 600 678 500 678 E1/E2, E9, F8/F9
130B3193 130B3194
450 800 600 730 530 730 E1/E2, E9, F8/F9
450 800 600 730 530 730 F1/F3, F10/F11, F18 2X130B3186 2X130B3187
500 880 650 780 560 780 F1/F3, F10/F11, F18
2X130B3188 2X130B3189
560 990 750 890 630 890 F1/F3, F10/F11, F18
630 1120 900 1050 710 1050 F1/F3, F10/F11, F18
2X130B3191 2X130B3192
710 1260 1000 1160 800 1160 F1/F3, F10/F11, F18
710 1260 1000 1160 800 1160 F2/F4, F12/F13
3X130B3188 3X130B3189
800 1460 F2/F4, F12/F13
1200 1380 1000 1380 F2/F4, F12/F13
3X130B3191 3X130B3192
1000 1720 1350 1530 1100 1530 F2/F4, F12/F13
Table 5.21 Sine-Wave Filter Modules, 380–500 V
How to Order Design Guide
MG34S222 Danfoss A/S © Rev. 2014-02-10 All rights reserved. 105
5 5
