SD260L/SD360/SD460 Installation and Administrator’s Guide A-1
Appendix A: SD460
Laminating System
This appendix provides information about the SD460 laminating system.
About the SD460 System
The SD460 system consists of a card printer and laminator. The SD460 system can print cards and
apply an overlay material on the front and back of the card for increased durability and security.
Using an overlay material with holographic or other transparent images also improves the
security of the card. These materials are tamper evident, making it difficult to reproduce or
modify a card.
Laminator
Printer

DataCard SD460 Specifications

General

Color	Yes
Card size	85.6 x 53.98 mm
Card types	Magnetic stripe (ISO 7811), PVC, Smart card
Print technology	Dye-sublimation/Resin Thermal transfer
Duplex print speed (color)	200 card/h
Display	LCD
Certification	cULus, FCC, I.C., CE, Ctick, VCCI, RoHS, WEEE, CCC, KCC
Product color	Black, Blue
Internal memory	128 MB
Built-in barcodes	1D, 2D
Total input capacity	100 sheets
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Wi-Fi	No
USB version	2.0
Ethernet interface type	Fast Ethernet
Storage temperature (T-T)	-15 - 60 °C
Operating temperature (T-T)	15 - 35 °C
Storage relative humidity (H-H)	10 - 90 %
Operating relative humidity (H-H)	20 - 80 %

Weight and Dimensions

Weight	13600 g
Dimensions (WxDxH)	589 x 270 x 513 mm
