DataCard SD460 Installation And Administrator's Guide

34 Elements of Card Design
Smart Card Codes on the Printer Label
The configuration label includes codes that identify the type and model of the smart card module
installed in the printer. The following table lists the codes used on the configuration label.
The S1 value on the configuration label indicates that the printer has the basic smart card
components installed. Basic components include the mounting hardware only. An integrator
must install a contactless reader.
If the Sx value is included in the configuration code, the printer has the basic components of an
S1, plus the appropriate interface installed.
Code on Label Type of Smart Card Module
S1 Integrator Contactless
S3 HID pcProx Contactless
S4 iCLASS Read Contactless
S5 iCLASS Read/Write Contactless
S6 DUALi Standard
S7 DUALi Single Wire
S8 DUALi Single Wire Sony Felica
S9 GEMPC USB / pcProx Dual
S10 Contact Station
S11 Identive Dual Interface Reader
S12 pcProx Plus Dual Frequency
S13 DUALi Single Wire Large Memory
The smart card readers available may vary by printer model. Contact your authorized
dealer for more information.

DataCard SD460 Specifications

General

Color	Yes
Card size	85.6 x 53.98 mm
Card types	Magnetic stripe (ISO 7811), PVC, Smart card
Print technology	Dye-sublimation/Resin Thermal transfer
Duplex print speed (color)	200 card/h
Display	LCD
Certification	cULus, FCC, I.C., CE, Ctick, VCCI, RoHS, WEEE, CCC, KCC
Product color	Black, Blue
Internal memory	128 MB
Built-in barcodes	1D, 2D
Total input capacity	100 sheets
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Wi-Fi	No
USB version	2.0
Ethernet interface type	Fast Ethernet
Storage temperature (T-T)	-15 - 60 °C
Operating temperature (T-T)	15 - 35 °C
Storage relative humidity (H-H)	10 - 90 %
Operating relative humidity (H-H)	20 - 80 %

Weight and Dimensions

Weight	13600 g
Dimensions (WxDxH)	589 x 270 x 513 mm
