REFERENCES
147
5.4.3 Address Stamping
It is possible to include the reader address in the message sent to the host. The
reader Address Stamping parameter consists of a 4-digit number in the range
0000-1999.
For message output format, refer to par. 5.4.
5.4.4 Address Delimiter
The Address Delimiter allows a character to be included to separate the reader
Address stamping field from the next field in the message. Any character can be
included in the hexadecimal range from 00 to FE.
For message output format, refer to par. 5.4.
5.5 POWER SAVE
5.5.1 Sleep State/USB Suspend
When using interfaces other than USB, this mode allows the μP in the reader to enter
a “Sleep” state for minimum power consumption. For D-series readers, this command
is only valid when hardware trigger type is selected.
Before entering Sleep mode, the following are verified:
• no commands coming from Host
• no data being transmitted to Host
• Enter Sleep Timeout ended (see par. 5.5.2)
To exit Sleep mode press the trigger.
Enabling the Sleep state implements Standby mode for CCD devices, see par. 5.5.3.
F
or M-Series readers, sleep state is
entered immediately after reading a code and is
not configurable. To exit Sleep mode press the trigger.
When using the USB interface, this mode allows the device to manage Selective
Suspend conditions generated by the Host Operating System in which optimizing low
power consumption (ex. Windows Stand-by). It is possible to exit the Suspend mode
either from the Host (ex. moving the mouse during Stand-by) or through the barcode
reader. The latter, called Remote Wakeup, makes the device wake up the Host
restoring the communication. Remote Wakeup is possible by pressing the trigger.
