TECHNICAL FEATURES
159
6 TECHNICAL FEATURES
6.1 GRYPHON™ D
Electrical Features
Supply Voltage 5 Vdc ± 5%
Consumption
Maximum
Operating
Sleep Mode/USB Suspend
330 mA
250 mA
<500 μA
Optical Features
Sensor CCD solid state (3648 pixels)
Scan Rate (max) 270 scans/sec
Reading field see reading diagram (par. 6.6)
Resolution (max) 0.076 mm (3 mils)
PCS (min) (Datalogic Test Chart) 15%
Environmental Features
Working Temperature 0° to +55 °C / +32° to +131 °F
Storage Temperature -20° to +70 °C / -4° to +158 °F
Humidity 90% non condensing
Drop resistance IEC 68-2-32 Test ED
Protection Class IP30
Mechanical Features
Weight (without cable) about 200 g. (7 oz.)
Dimensions 179 x 81 x 98 mm / 7.04 x 3.18 x 3.85 in
Material ABS and Polycarbonate molded with rubber
