Enter Configuration
Exit and Save Configuration
Ì$+;Î
RS232
Ì$
-
?Î
34
I
NTER
-
CHA
RACTER
D
ELA
Y
delay between characters transmitted to Host
ÌCK3Î
Read 2 numbers from the table where
:
00 =
DELAY
disabled
01-99 =
DELAY from 1 to 99 milliseconds
delay disabled
R
X
T
IMEOUT
timeout control in reception from Host
ÌCL5Î
Read 2 numbers from the table where:
00 =
TIMEOUT disabled
01-99 =
TIMEOUT from
.1
to
9.9
seconds
rx timeout 5 seconds
See par.
5.1.4
for details.
41
43
Table of Contents
Default Chapter
3
Default Chapter
3
Table of Contents
3
General View
8
1 Introduction
9
2 Installation
10
GRYPHON™ D Interface Cable Connections
10
OM-GRYPHON™ Interface Cable Connections
11
RS232 Connection
12
Usb
12
Ibm Usb Pos
13
WEDGE Connection
13
PEN Emulation Connection
14
GRYPHON™ M Battery Maintenance
15
Battery Type
15
Battery Charging
15
Replacing GRYPHON™ M Batteries
15
3 Gryphon™ M System and Network Layouts
17
Stand Alone Layouts
17
Single Reader Layout
17
Multiple Reader Layout
17
Multiple Stand Alone Layouts
18
Multidrop STAR-System™ Network Layouts
19
Host Master Layout
19
4 Configuration
20
Configuration Methods
20
Reading Configuration Barcodes
20
Using DL Sm@Rtset
20
Copy Command
20
Sending Configuration Strings from Host
21
Setup Procedures
21
GRYPHON™ D Setup
22
GRYPHON™ M/OM-GRYPHON™ Stand Alone Setup
22
Using Multiple M-Series Readers with same Cradle
24
GRYPHON™ M/STAR-Modem™ in Stand Alone Mode
25
GRYPHON™ M/STAR-System™ Setup
26
Interface Selection
28
USB Reader Configuration
33
Changing Default Settings
36
Rs232 Parameters
37
Baud Rate
38
Parity
39
Data Bits
39
Stop Bits
40
Handshaking
40
Ack/Nack Protocol
41
Fifo
41
Inter-Character Delay
42
Rx Timeout
42
Serial Trigger Lock
43
Usb Parameters
44
Handshaking
45
Ack/Nack Protocol
45
Fifo
46
Inter-Character Delay
46
Rx Timeout
47
Serial Trigger Lock
47
Keyboard Nationality
48
Fifo
49
Inter-Character Delay
49
Inter-Code Delay
50
Wedge Parameters
51
Keyboard Nationality
52
Caps Lock
53
Caps Lock Auto-Recognition (IBM at Compatible Only)
53
Num Lock
54
Inter-Character Delay
54
Inter-Code Delay
55
Keyboard Setting
56
Pen Emulation
58
Operating Mode
59
Minimum Output Pulse
60
Conversion to Code 39 and Code 128
61
Overflow
62
Output Level
62
Idle Level
63
Inter-Block Delay
63
IBM 46Xx
64
IBM Data Formatting
65
Data Format
66
Code Identifier
70
Custom Code Identifier
71
Header
72
Terminator
73
Field Adjustment
75
Field Adjustment Character
77
Code Length Tx
77
Character Replacement
78
Address Stamping (M Series Only)
81
Address Delimiter (M Series Only)
81
Power Save
82
Scan Rate
83
Sleep State/Usb Suspend
83
Enter Sleep Timeout
84
Standby
84
Reading Parameters
85
Operating Mode
87
Hand-Held Operation
87
Stand Operation
88
Hardware Trigger Mode
88
Trigger-Off Timeout
88
Flash Mode
89
Reads Per Cycle
89
Safety Time
90
Beeper Intensity
90
Beeper Tone
91
Beeper Type
91
Beeper Length
91
PDF Decoding Recognition Intensity
92
Good Read Spot Duration
92
Decoding Parameters
93
Ink Spread
94
Overflow Control
94
Interdigit Control
95
Decoding Safety
95
Puzzle Solver
96
Code Selection
97
Code 93
97
EAN/UPC Family
100
2/5 Family
104
Code 39 Family
105
Code 128 Family
107
Codabar Family
109
Msi
111
Plessey
112
Telepen
113
Delta IBM
114
Code 11
115
Code 16K
116
Code 49
116
Pdf417
117
RSS Codes
118
Advanced Formatting
119
Concatenation
121
Advanced Formatting
124
Radio Parameters
141
Radio Protocol Timeout
142
Power-Off Timeout
142
Beeper Control for Radio Response
143
Battery Type
143
Single Store
144
5 References
145
RS232 Parameters
145
Handshaking
145
ACK/NACK Protocol
146
Fifo
147
RX Timeout
148
Pen Parameters
148
Minimum Output Pulse
148
Conversion to Code 39 and Code 128
148
Overflow
149
Output and Idle Levels
149
Inter-Block Delay
150
IBM 46Xx Parameters
150
IBM Data Formatting (Transmission Format)
150
Data Format
151
Header/Terminator Selection
151
Set Custom Extended Header/Terminator Keys
153
Address Stamping
155
Address Delimiter
155
Power Save
155
Sleep State/Usb Suspend
155
Enter Sleep Timeout
156
Standby
156
Reading Parameters
156
Operating Mode
156
Hardware Trigger Mode
157
Trigger-Off Timeout
157
Reads Per Cycle
157
Safety Time
158
Decoding Parameters
158
Ink-Spread
158
Overflow Control
158
Interdigit Control
158
Radio Parameters (M Series Only)
159
Radio Protocol Timeout
159
Power-Off Timeout
159
Beeper Control for Radio Response
159
Single Store
160
Configuration Editing Commands
161
5.10 Configuration Copying Commands
162
Copy GRYPHON™ D-Series
162
Copy GRYPHON™ M-Series
163
Copy OM-GRYPHON
164
5.11 C-Gryphon™ Configuration
165
5.12 Default Parameters for Pos Terminals
166
6 Technical Features
167
Gryphon™ D
167
Gryphon™ M
168
Om-Gryphon™ / C-Gryphon
169
System and Radio Features
170
Status Indicators
170
Reading Diagrams
172
Ahost Configuration Strings
174
Bcode Identifier Table
187
Hex and Numeric Table
190
