REFERENCES
155
5.10.2 Copy GRYPHON™ M-Series
Procedure:
c
Using the slave reader and its OM-Gryphon™ cradle, follow the initialization
procedure in chapter 4 of this manual or from the Quick Reference Manual.
d
With the master Gryphon™ M (correctly configured reader), read the Copy
Configuration barcode below. Then place it onto an OM-Gryphon™ cradle within
10 seconds. The reader will beep indicating the configuration has been copied.
The configuration will be simultaneously sent over the RS232 interface of the
OM-Gryphon™. If this causes undesired effects disconnect the RS232 cable
between the PC and OM-Gryphon™ during this process.
Copy Configuration
Ì$+ZZ0$-*Î
e
With the slave Gryphon™ M, read the Get Configuration barcode below. Then
place it onto the same OM-Gryphon™ cradle used in the step above. The slave
reader's address will not be changed.
Get Configuration
Ì$+ZZ2$-4Î
The configuration will be copied from the master to the slave Gryphon™ M. The
slave Gryphon™ M signals the end of the procedure with a series of beeps. It is now
ready to be used with its own OM-Gryphon™ cradle.
f
Repeat the procedure above to configure other slave readers. The
OM-Gryphon™ can continue to configure slave readers until it receives another
command or data.
