4.1.4 Sending Configuration Strings from Host
An alternative configuration method is provided in Appendix A using the RS232
interface. This method is particularly useful when many devices need to be
configured with the same settings. Batch files containing the desired parameter
settings can be prepared to configure devices quickly and easily.
4.2 SETUP PROCEDURES
For Gryphon™ D-Series readers, follow the setup procedures in pars. 4.3 and 4.6.
For Gryphon™ D USB readers, follow the setup procedures in par. 4.7.
Fo
r Gryphon™ M-Series readers, the setup procedures depend on two
basic
applications, Stand Alone or STAR-System™.
Stand Alone applications allow communication with the Host by either the
OM-Gryphon™ cradle (par. 4.4), or by the STAR-Modem™ radio modem
(par. 4.4.2).
ST
AR-System™ applications allow communication w
ith the Host through an RS485
network by the STARGATE™ RF base station or by the STAR-Modem™ radio
modem (par. 4.5).
Proceed as shown in the following diagram:
End of Setup
Your reader is now ready to read
barcodes using the default settings.
Stand Alone Applications
GRYPHON™ M/OM-GRYPHON™
Par. 4.4
Par. 4.6
Optional Par. 4.4.1
m ultiple guns per OM-GRYPHO N™
GRYPHON™ M/STAR-Modem™
in Stand Alone Mode
Par. 4.4.2
GRYPHON™ D
Par. 4.3
Par. 4.6
STAR-System ™ Applications
GRYPHON™ M/STAR-System™
Par. 4.5
•
STARGATE™
•
STAR-Modem™ in STAR-System™ Mode
GRYPHON™ D USB
Par. 4.7
Begin Setup by choosing the setup
procedure for your GRYPHON™
reader as indicated below.
To Next Page
