GRYPHON™
160
6.2 GRYPHON™ M
Electrical Features
Battery Type 2 AA NiMh* batteries
1.2 V – 1400 mAh
Time of recharge NiMh From 3 to 5 hours
Operating autonomy
(typ. continuous reading)
25,000 reads - NiMh
Indicators LED, Good Read Spot, Beeper
Optical Features
Sensor CCD solid state (3648 pixels)
Scan Rate (max) 270 scans/sec
Reading field see reading diagram (par. 6.6)
Resolution (max) 0.076 mm (3 mils)
PCS (min) (Datalogic Test Chart) 15%
Environmental Features
Working Temperature 0 to +40 °C / +32° to +104 °F
Storage Temperature
(without battery)
-20 to +70 °C / -4° to +158 °F
Humidity 90% non condensing
Drop resistance IEC 68-2-32 Test ED
Protection class IP30
Mechanical Features
Weight (with batteries) about 280 g. / 9.87 oz
Dimensions 179 x 81 x 98 mm / 7.04 x 3.18 x 3.85 in
Material ABS and Polycarbonate molded with rubber
* It is possible to employ also NiCd or non-chargeable Alkaline AA batteries.
