MICRO PDF417 ENTER/EXIT PROGRAMMING MODE
PRODUCT REFERENCE GUIDE
215
Micro PDF417 Length Control
This feature specifies either variable length decoding or fixed length decoding for this
symbology.
Variable Length:
For variable length decoding, a minimum and maximum length may
be set.
Fixed Length:
For fixed length decoding, two different lengths may be set.
Micro PDF417 Set Length 1
Specifies one of the bar code lengths for "Micro PDF417 Length Control" on page 215.
Length 1 is the minimum label length if in Variable Length Mode, or the first fixed length
if in Fixed Length Mode. Length includes the bar code’s data characters only. Characters
can be set from 0001 to 0366 characters (pad with zeroes) in increments of 01. Any
value greater than 0366 will be considered to be 0366.
See "
Set Length 1" on page 288 for detailed instructions on setting this feature.
$CMILC00
Micro PDF417 Length Control = Variable Length
Micro PDF417 Length Control = Fixed Length
$CMILC01
Select Micro PDF417 Length 1 Setting
$CMIL1
To configure this feature, scan the ENTER/EXIT PRO-
GRAMMING MODE bar code above, then the bar
code at left followed by the digits from the Alphanu-
meric characters in Appendix D, Keypad represent-
ing your desired character(s). End by scanning the
ENTER/EXIT bar code again.
Make a mistake? Scan the CANCEL bar code to abort
and not save the entry string. You can then start
again at the beginning.
CANCEL
0001 = Length 1 is 1 Character
To Next Page
