SETUP
16
QUICKSCAN™ 2500
BASE STATION INSTALLATION
The base station/charger may be set up in desk application standalone or with the addi-
tional tilting platform, which allows to adjust the inclination of the scanner to provide
the most comfortable use depending on the needs.
Figure 7. Presentation Position
This position is preferred, if the scanner is to be used in stand mode and not needed to
be often removed from base station.
Figure 8. Tilting Platform Position
This optional tilting platform allows to adjust the scanner inclination to different angle
positions.
