SYSTEM AND NETWORK LAYOUTS
PRODUCT REFERENCE GUIDE
21
SYSTEM AND NETWORK LAYOUTS
Stand Alone Layouts
Figure 15 - Single Reader Layout
Figure 16 - Multiple Stand Alone Layout
Many stand alone connections can operate in the same physical area without interfer-
ence, provided all readers and cradles in the system have different addresses.
HOST
CRADLE
QBT2500
