Datalogic QuickScan QD2590 User Manual

PRODUCT REFERENCE GUIDE 103
CONFIGURATION | 1D SYMBOLOGIES
SECTION CONTENTS
D
ISABLE ALL SYMBOLOGIES starting on page 104
•
COUPON CONTROL starting on page 104 • INTERLEAVED 2 OF 5 (I 2 OF 5) starting
on page 138
•
UPC-A starting on page 105 • INTERLEAVED 2 OF 5, FEBRABAN
(D
ESK MODELS ONLY) starting on page
143
•
UPC-E starting on page 107 • INTERLEAVED 2 OF 5 CIP HR starting on
page 144
•
EAN-13 starting on page 110 • MATRIX 2 OF 5 starting on page 145
•
EAN-8 starting on page 113 • STANDARD 2 OF 5 starting on page 148
•
UPC/EAN GLOBAL SETTINGS starting
on page 115
• COMPRESSED 2 OF 5 starting on page 151
• GS1 DATABAR™ OMNIDIRECTIONAL
starting on page 119
• DATALOGIC 2 OF 5 starting on page 154
•
GS1 DATABAR™ EXPANDED starting on
page 120
• INDUSTRIAL 2 OF 5 starting on page 157
• GS1 DATABAR™ LIMITED starting on
page 123
• IATA starting on page 160
•
CODE 39 starting on page 124 • FOLLETT 2 OF 5 starting on page 161
•
TRIOPTIC CODE starting on page 129 • CODABAR starting on page 162
•
CODE 39 DANISH PPT starting on page
129
• ABC CODABAR starting on page 168
• CODE 39 PZN starting on page 130 • ISBT 128 starting on page 170
•
CODE 39 LA POSTE starting on page 130 • CODE 11 starting on page 173
•
CODE 32 (ITALIAN PHARMACEUTICAL)
starting on page 131
• CODE 93 starting on page 176
•
CODE 39 CIP HR (FRENCH PHARMA-
CEUTICAL) starting on page 132
• MSI starting on page 180
• CODE 128 starting on page 133 • PLESSEY starting on page 183
•
GS1-128 starting on page 137 • BC412 starting on page 186

Datalogic QuickScan QD2590 Specifications

General

Type	Handheld bar code reader
Sensor type	-
Scanner type	1D/2D
Scanner resolution	0.17 mm
Tilt reading angle	0 - 360 °
Pitch reading angle	0 - 65 °
Light levels (direct sunlight)	0 - 100000 lx
Linear (1D) barcodes supported	CPC Binary, Codabar, Codabar 125, Code 11, Code 128, Code 128A, Code 128B, Code 128C, Code 25 (IR 2 of 5), Code 25 (non-IR 2 of 5), Code 3 of 9, Code 32, Code 39, Code 93, DUN 14, DataBar14, Discrete 2 of 5, EAN 128, EAN 2, EAN 5, EAN-13, EAN-8, Facing Identification Mark, GS1 DataBar, GS1 DataBar Expanded, GS1 DataBar Omnidirectional, GS1 Databar Limited, GS1-128 (UCC/EAN-128), HIBC, IATA, ISBN, ISSN, ITF-14, ITF-6, Industrial 2 of 5, Intelligent Mail, Interleaved 2 of 5, JAN, Latent image, MSI, Matrix 2 of 5, PDF417, PLANET, POSTNET, Pharmacode, Plessey, PostBar, RM4SCC / KIX, S-Code, Telepen, Trioptic, U.P.C., UPC-A, UPC-E
Optical sensor resolution (W x H)	1280 x 800 pixels
2D (matrix & stacked) barcodes supported	Aztec Code, Data Matrix, Dot Code A, MaxiCode, Micro QR Code, QR Code
Cable length	2 m
Standard interfaces	USB
Connectivity technology	Wired
Product color	Black
Image formats supported	BMP, JPEG, TIFF
International Protection (IP) code	IP52
Input voltage	5 V
Power consumption	450 mA
Cables included	USB Type-C
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 50 °C
Operating relative humidity (H-H)	0 - 95 %
Sustainability certificates	RoHS
Material	Polyvinyl chloride (PVC)
Connector 1	USB C
Product type	USB cable
Connector gender	Male/Male
Brand compatibility	Datalogic
Connector 1 form factor	Straight
Harmonized System (HS) code	84733020

Weight and Dimensions

Depth	126 mm
Width	148 mm
Height	68 mm
Weight	145 g
