Memory modules
Removing the memory modules
Prerequisites
1. Follow the procedure in Before working inside your computer.
2. Remove the base cover.
About this task
The following image indicates the location of the memory modules and provides a visual representation of the removal procedure.
Steps
1. Use your fingertips to carefully spread apart the securing-clips on each end of the memory-module slot until the memory module pops
up.
2. Slide and remove the memory module from the memory-module slot.
NOTE: Repeat step 1 and step 2 to remove the other memory module, if installed on your computer.
Installing the memory modules
Prerequisites
If you are replacing a component, remove the existing component before performing the installation procedure.
About this task
The following image indicates the location of the memory modules and provides a visual representation of the installation procedure.
Removing and installing components
35
