Steps
1. Align the notch on the memory module with the tab on the memory-module slot.
2. Slide the memory module firmly at an angle, into the memory-module slot.
3. Press the memory module down until it clicks into place.
NOTE: If you do not hear the click, remove the memory module and reinstall it.
NOTE: Repeat step 1 to step 3 to install the other memory module, if available on your computer.
Next steps
1. Install the base cover.
2. Follow the procedure in After working inside your computer.
Processor fan
Removing the processor fan
Prerequisites
1. Follow the procedure in Before working inside your computer.
2. Remove the base cover.
About this task
The following image indicates the location of the processor fan and provides a visual representation of the removal procedure.
36
Removing and installing components
