Back to Contents Page
System Board
Dell™Inspiron™1090ServiceManual
Removing the System Board
Replacing the System Board
Entering the Service Tag in the BIOS
Removing the System Board
1. Follow the instructions in Before You Begin.
2. Remove the label door (see Removing the Label Door).
3. Remove the keyboard (see Removing the Keyboard).
4. Remove the palm-rest assembly (see Removing the Palm-Rest Assembly).
5. Remove the battery (see Removing the Battery).
6. Remove the memory module (see Removing the Memory Module).
7. Remove the Mini-Card(s) (see Removing the Mini-Card(s)).
8. Remove the hard-drive assembly (see Removing the Hard-Drive Assembly).
9. Remove the coin-cell battery (see Removing the Coin-Cell Battery).
10. Remove the processor fan and heat-sink assembly (see Removing the Processor Fan and Heat-Sink Assembly).
11. Remove the display assembly (see Removing the Display Assembly).
12. Disconnect the AC-adapter connector cable from the connector on the system board.
13. Disconnect the speaker cable from the connector on the system board.
14. Remove the six screws that secure the system board to the computer base.
WARNING: Before working inside your computer, read the safety information that shipped with your computer. For additional safety best
practices information, see the Regulatory Compliance Homepage at www.dell.com/regulatory_compliance.
CAUTION: To avoid electrostatic discharge, ground yourself by using a wrist grounding strap or by periodically touching an unpainted metal
surface (such as a connector on your computer).
