Dell Latitude D531 User Manual

Before You Begin 117
• In the Microsoft Windows Vista™ operating system , click the Windows Vista Start button → Help
and Support
→ Computer Information .
DIMM B Connector
To install a memory module in the DIMM B connector:
1
Follow the procedures in "Before You Begin" on page 109.
2 Turn the computer upside-down, loosen the captive screw on the memory module cover (see "Bottom
View" on page 23), and remove the cover.
NOTICE: To prevent damage to the memory module connector, do not use tools to spread the memory-module
securing clips.
3 If you are replacing a memory module, remove the existing module:
a Use your fingertips to carefully spread apart the securing clips on each end of the memory module
connector until the module pops up.
b Remove the module from the connector.
1 captive screw 2 memory module cover
1
2

Dell Latitude D531 Specifications

General

Hard Drive Interface	SATA
Processor	AMD Turion 64 X2 or AMD Sempron
RAM	Up to 4GB DDR2
Display	15.4-inch WXGA (1280x800) or WXGA+ (1440x900)
Graphics	ATI Radeon X1270
Storage	Up to 160GB HDD
Optical Drive	DVD-ROM, DVD+/-RW
Operating System	Windows Vista, Windows XP
Wireless	Dell Wireless 1390
Ports	4 x USB 2.0, VGA, Ethernet, Modem, Headphone, Microphone
