Using Cards 69
Removing a PC Card or Blank
CAUTION: Before you begin any of the procedures in this section, follow the safety instructions in the
Product Information Guide and see "Before Working Inside Your Computer" on page 110.
NOTICE: Use the PC Card configuration utility (click the icon in the taskbar) to select a card and
stop it from functioning before you remove it from the computer. If you do not stop the card in the
configuration utility, you could lose data. Do not attempt to eject a card by pulling its cable, if one is
attached.
Press the latch and remove the card or blank. For some latches, you must press the latch twice: once
to pop the latch out, and then a second time to pop the card out.
Save a blank to use when no PC Card is installed in a slot. Blanks protect unused slots from dust
and other particles.
1 slot 2 ExpressCard
1
2

Dell Latitude D531 Specifications

General

Hard Drive Interface	SATA
Processor	AMD Turion 64 X2 or AMD Sempron
RAM	Up to 4GB DDR2
Display	15.4-inch WXGA (1280x800) or WXGA+ (1440x900)
Graphics	ATI Radeon X1270
Storage	Up to 160GB HDD
Optical Drive	DVD-ROM, DVD+/-RW
Operating System	Windows Vista, Windows XP
Wireless	Dell Wireless 1390
Ports	4 x USB 2.0, VGA, Ethernet, Modem, Headphone, Microphone
